Panels with radiological shielding depending on the demand especially recommended for specialized X-ray rooms or operating theatres.
The anti-X-ray door structure aims at reducing the intensity of gamma rays reaching the site to a value lower than the maximum permissible. Radiological protection inside our door consists of lead input of equivalent in the range of PB # 0.5 mm to # 3 mm.

Specifications:

•    The panels are constructed using galvanized steel gr. 1.5 mm consisting of bonds connected by staples, made of vertical and transverse profiles, which form a stable     scaffolding
•    Mounting points of the coffers (wall panels) on the construction are inapparent
•    Standard ceiling tiles modules are in dimensions of 600x600 or 1200x600
•    20 mm thick wall panels made of 1 mm thick stainless steel are constructed in multi-    layer technology and finished with stainless steel 1.4301
•    The wall structure enables easy removal of a single panel to carry out additional changes in the installation and construction
•    The antibacterial hermetic silicone silver pressure gasket is applied
•    The system for construction of ceilings guarantees an equal level of planes, effortless    assembly and disassembly
•    The ceiling panels system for operating theatres is a coherent and consistent     complement to modular wall system. Wall panels can be adjusted to the distance     between the axes of the grid ceiling system and removed one by one
•    The elimination of the risk of contamination in the corners through application of bent panels without contacts and joints in the corners
•    Installation creates a sealed surface adapted to gas decontamination
•    anti-X-rays shield in the form of lead input of thickness from #0.5 to #3.

Panels with radiological shielding

They are a safe solution used in dental X-rays, but also in modern operating rooms

•    panel surface finish: natural stainless steel with a polished structure, glass surface, surface painted in RAL colours, with silver ions
•    Heating filler in the form of an internal panel with a heating output of about 90 Wm2.
